ASUS ROG STRIX X670E-I GAMING WIFI Mini-ITX Motherboard Ryzen 7000 Socket AM5 LGA1718 2x DDR5 DIMM Slots Max 64GB PCIe 5.0

Specifications

CPU

AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*
* Refer to www.asus.com for CPU support list.

Chipset

AMD X670

Memory

• 2 x DIMM, Max. 64GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800MHz ECC and Non-ECC, Un-buffered Memory*

• Dual Channel Memory Architecture

• Supports AMD EXTended Profiles for Overclocking (EXPO™)

• OptiMem II

* Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
* Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function

Graphics

• 1 x HDMI^® port*

• 2 x USB4^® ports support USB Type-C^® display outputs**

*Supports 4K@60Hz as specified in HDMI 2.1.
** VGA resolution support depends on processors' or graphic cards' resolution.

Expansion Slots

AMD Ryzen™ 7000 Series Desktop Processors
1 x PCIe 5.0 x16 slot(s)

Storage

Total supports 2 x M.2 slots and 2 x SATA 6Gb/s ports*

AMD Ryzen™ 7000 Series Desktop Processors

• M.2_1 slot (Key M), type 2280(supports PCIe 5.0 x4 mode)

AMD X670 Chipset

• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

• 2 x SATA 6Gb/s ports****

*AMD RAIDXpert2 Technology supports both NVMe RAID 0/1 and SATA RAID 0/1.

**** Install ROG FPS-II Card to support 2 x SATA 6Gb/s ports

Ethernet

1 x Intel^® 2.5Gb Ethernet
ASUS LANGuard

Wirelesss & Bluetooth

Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band*
Bluetooth v5.2

* WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later.

USB

Rear USB (Total 10 ports)

• 2 x USB4^® port(s) with Intel^® JHL8540 USB4^® controller (2 x USB Type-C^®)

• 5 x USB 3.2 Gen 2 port(s) (5 x Type-A)

• 3 x USB 2.0 port(s) (3 x Type-A)



Front USB (Total 3 ports)

• 1 xUSB 3.2 Gen 2 connector (supports USB Type-C^®)

• 1 x USB 3.2 Gen 1 header(s) support(s)

• additional 2 USB 3.2 Gen 1 ports



ROG STRIX HIVE (Total 2 ports)

• 1 x USB 3.2 Gen 2 port(s) (1 x USB Type-C^®)

• 1 x USB 2.0 port(s) (1 x Type-A



ROG FPS-II C (Total 3 ports)

• 2 x USB 2.0 header(s) additional 3 USB 2.0 ports**

Audio

ROG High Definition Audio CODEC ALC4050

• Supports: Jack-detection

• High quality 118 dB SNR stereo playback output and 94 dB SNR recording input

• Supports up to 32-Bit/384 kHz playback



Audio Features

• ROG Hyper-Grounding Technology

• ESS^® SABRE9260Q DAC

• Silver-plated audio jacks

• Optical S/PDIF out port & USB Type-C^®  port with indepent power solution

• Dedicated audio PCB layers

*All audio functions on ROG STRIX X670E-I GAMING WIFI are supported through ROG STRIX HIVE

Back Panel I/O Ports

• 2 x USB4^® port(s) with Intel^® JHL8540 USB4^® controller (2 x USB Type-C^®)

• 5 x USB 3.2 Gen 2 port(s) (5 x Type-A) (1 port supports ROG STRIX HIVE)

• 3 x USB 2.0 port(s) (3 x Type-A)

• 1 x HDMI^® port

• 1 x Wi-Fi Module

• 1 x Intel^® I225-V 2.5Gb Ethernet port

Internal I/O Connectors

Fan and Cooling related
1 x 4-pin CPU Fan header(s)
1 x 4-pin AIO Pump header(s)
1 x 4-pin Chassis Fan header(s)
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
USB
1 x USB 3.2 Gen 2 connector (support(s) USB
Type-C^® )
1 x USB 3.2 Gen 1 header(s) support(s)
additional 2 USB 3.2 Gen 1 ports
Miscellaneous
1 x Addressable Gen 2 header(s)
1 x AURA RGB header(s)
1 x RTC Battery header
1 x Thermal Sensor header
1 x 2 pin Power_BTN header
2 x USB Type-C^® connectors to Install ROG
FPS-II card*
ROG FPS-II card
2 x SATA 6Gb/s ports
1 x CPU Over Voltage jumper
1 x Clear CMOS header
1 x Front Panel header
1 x Alteration mode switch
2 x USB 2.0 header(s) support(s) additional
3 USB 2.0 ports

Special Features

Extreme Engine Digi+
-5K Black Metallic Capacitors
ASUS Q-Design
- M.2 Q-Latch
- Q-DIMM
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink
- Aluminum backplate
- M.2 Chipset Fan
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- ProCool II
- Pre-mounted I/O shield
- SafeSlot
- SafeDIMM
AURA Sync
- AURA RGB header(s)
- Addressable Gen 2 header(s)
ROG STRIX HIVE
1 x USB Type-C^® connects to Motherboard
1 x USB 3.2 Gen 2 port(s) (1 x USB Type-C^®)
1 x USB 2.0 port(s) (1 x Type-A with BIOS
FlashBack™)
1 x Headphone jack with Mic in
1 x Mic in jack with Optical S/PDIF out
1 x EZ mode PBO button
1 x FlexKey button
1 x BIOS FlashBack™  button
1 x Volume Control Knob with Mute Button
Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])

Software Features

ROG Exclusive Software
- GameFirst VI
- ROG CPU-Z
- Sonic Studio III + Sonic Studio Virtual
Mixer + Sonic Suite Companion
- Sonic Radar III
- DTS^® Sound Unbound
- Anti-virus software
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (60 days free trial)
- AURA Creator
- AURA Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
- Two-Way AI Noise Cancellation
AI Suite 3
- TPU
- DIGI+ VRM
- Turbo app
- PC Cleaner
MyAsus
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
Dynamic OC Switcher
FlexKey

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables
2 x SATA 6Gb/s cables
1 x ROG USB2.0 splitter cable
1 x Panel Cable
ROG FPS-II Card
1 x ROG FPS-II Card
ROG STRIX HIVE
1 x ROG STRIX HIVE
1 x USB Type-C^® power connection cable
Additional Cooling Kit
1 x Thermal pad for M.2
Miscellaneous
1 x ASUS Wi-Fi moving antennas
1 x Cable ties pack
1 x Rubber Package(s) for M.2
1 x Q-Latch package(s) for M.2
1 x ROG key chain
1 x ROG Strix stickers
1 x ROG Strix thank you card
Installation Media
1 x User guide

Operating System

Windows^® 11, Windows^® 10 64-bit

Form Factor

Mini-ITX Form Factor
6.7 inch x 6.7 inch( 17cm x 17cm)
