ASUS ROG STRIX X670E-A GAMING WIFI ATX Motherboard Ryzen 7000 Socket AM5 LGA1718 4x DDR5 DIMM Slots Max 128GB PCIe 5.0

Specifications

CPU

AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*

* Refer to www.asus.com for CPU support list.

Chipset

AMD X670

Memory

• 4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory*

• Dual Channel Memory ArchitectureSupports AMD EXTended Profiles for Overclocking (EXPO™)OptiMem II

* Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
* Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function

Graphics

• 1 x DisplayPort*

• 1 x HDMI^® port**

* Supports max. 8K@60Hz as specified in DisplayPort 1.4.
** Supports Supports 4K@60Hz as specified in HDMI 2.1.

Expansion Slots

AMD Ryzen™ 7000 Series Desktop Processors

• 1 x PCIe 5.0/4.0/3.0 x16 slot



AMD X670 Chipset

• 1 x PCIe 4.0/3.0 x16 slot (supports x4 mode)

• 1 x PCIe 3.0 x1 slot

Storage

Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*

AMD Ryzen™ 7000 Series Desktop Processors

• M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)

• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)



AMD X670 Chipset

• M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

• 4 x SATA 6Gb/s ports

*AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10

Ethernet

1 x Intel^® 2.5Gb Ethernet

ASUS LANGuard

Wireless & Bluetooth

• Wi-Fi 6E

• 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)

• Supports 2.4/5/6GHz frequency band*

• Bluetooth v5.2

* WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later.

USB

Rear USB (Total 12 ports)

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C^®)

• 8 x USB 3.2 Gen 2 ports (7 x Type-A + 1 x USB Type-C^®)

• 1 x USB 3.2 Gen 1 port (1 x Type-A)

• 2 x USB 2.0 ports (2 x Type-A)



Front USB (Total 7 ports)

• 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C^® )

• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports

• 2 x USB 2.0 headers support additional 4 USB 2.0 ports

Audio

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

• Impedance sense for front and rear headphone outputs

• Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

• High quality 120 dB SNR stereo playback output and 113 dB SNR recording input

• Supports up to 32-Bit/384 kHz playback



Audio Features

• SupremeFX Shielding Technology

• Savitech SV3H712 AMP

• Rear optical S/PDIF out port

• Premium audio capacitors

• Audio cover

Back Panel I/O Ports

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C^®)

• 8 x USB 3.2 Gen 2 ports (7 x Type-A, 1 x USB Type-C^®)

• 1 x USB 3.2 Gen 1 port (1 x Type-A)

• 2 x USB 2.0 ports (2 x Type-A)

• 1 x DisplayPort

• 1 x HDMI^® port

• 1 x Wi-Fi Module

• 1 x Intel^® I225-V 2.5Gb Ethernet port

• 5 x Audio jacks

• 1 x Optical S/PDIF out port

• 1 x BIOS FlashBack™  button

• 1 x Clear CMOS button

Internal I/O Connectors

Fan and Cooling related

• 1 x 4-pin CPU Fan header

• 1 x 4-pin CPU OPT Fan header

• 1 x 4-pin AIO Pump header

• 5 x 4-pin Chassis Fan headers


Power related

• 1 x 24-pin Main Power connector

• 2 x 8-pin +12V Power connector

• Storage related

• 4 x M.2 slots (Key M)

• 4 x SATA 6Gb/s ports


USB

• 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C^® )

• 1 x USB 3.2 Gen 1 header supports additional

• 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 ports


Miscellaneous

• 3 x Addressable Gen 2 headers

• 1 x Aura RGB header

• 1 x CPU Over Voltage jumper

• 1 x Front Panel Audio header (AAFP)

• 1 x 20-3 pin System Panel header with Chassis intrude function

• 1 x Thermal Sensor header

• 1 x Thunderbolt™  header

Special Features

Extreme Engine Digi+

• 5K Black Metallic Capacitors



ASUS Q-Design

• M.2 Q-Latch

• PCIe Slot Q-Release

• Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])

• Q-Slot



ASUS Thermal Solution

• M.2 heatsink backplate

• M.2 heatsink

• VRM heatsink design



ASUS EZ DIY

• BIOS FlashBack™ button

• BIOS FlashBack™ LED

• Clear CMOS button

• ProCool II

• Pre-mounted I/O shield

• SafeSlot

• SafeDIMM

AURA Sync

• AURA RGB header

• Addressable Gen 2 headers

Software Features

ROG Exclusive Software
- GameFirst VI
- ROG CPU-Z
- Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion
- Sonic Radar III
- DTS^® Sound Unbound
- Anti-virus software

ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (60 days free trial)
- AURA Creator
- AURA Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
- Two-Way AI Noise Cancellation
AI Suite 3
- TPU
- DIGI+ VRM
- Turbo app
- PC Cleaner
MyAsus
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
FlexKey

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables
2 x SATA 6Gb/s cables

Additional Cooling Kit
1 x Thermal pad for M.2

Miscellaneous
1 x ASUS Wi-Fi moving antennas
1 x Cable ties pack
1 x M.2 Q-Latch packages for M.2 backplate
1 x M.2 Q-Latch package
1 x ROG key chain
1 x ROG Strix sticker
1 x ROG Strix thank you card
2 x Rubber Packages for M.2
1 x Rubber Package for M.2 backplate

Documentation
1 x User guide

Operating System

Windows^® 11, Windows^® 10 64-bit

Form Factor

ATX
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
